HORS PRODUCTION
TVT73FAHD
MINI DOME AHD CAMERA - TVT73FAHD
Mini dome vandal proof camera Day&Night suitable for outdoor application with 6mm integrated fixed lens. It is equipped with a new CMOS 1/2.9" SONY sensor of 2.1MP which joined with AHD technology, provides high definition pictures of up to 1080p. The built-in joystick in the cable allows to control all the OSD function for exposure adjusting and other features. The 24 IR led's and photocell make it suitable also for night time applications. IP65 protection degree. It is possible to switch the video output mode from AHD to analogue (CVBS) one to apply this camera to analogue DVR/monitors or to CVI/TVI video output for compatibility with third party recorders. Product not available any more.
main
characteristics
material: Aluminium
mounting
wall mounting: Wall/ceiling
wall mounting: Wall/ceiling
colour: White
IP degree: IP65
camera type: Sensor CMOS 1/2.9" (Sony)
resolution: 1920x1080
sensitivity: 0.01lux
lens: fixed
focal lenght: 6mm
functions
technical
features
supply voltage: 12Vdc
max current consumption: 350mA
dimensions
height cm. 9,3
width cm. 13,1
